JOBSITE CAMERA

Months of construction captured in minutes of time lapse video!

The Brinno Construction Camera is the effortless way to record any construction project. Set it and forget it. Create a time lapse video recorded at the rate you choose and played back at the speed you select when the project is complete.




Long Term Project Recording!

The Brinno Time Lapse Construction Camera is the effortless way to record any construction project. Set it and forget it. Get a time lapse video recorded at the rate you want, and played back at the rate you want when the project is done.

Dedicated Project Time Lapse Camera

Do you still use a DSLR to capture construction photos? Then spend a lot of time combining those photos into a time lapse video? Drop the traditional way, now you have better choice! Brinno Construction Camera produces Ready-to-View time lapse video in the camera with one button! You never knew how easy it could be!

Over 2 Months Battery Life

Brinno Construction Camera operates on long-lasting batteries. 4 AA batteries can last up to 4 months. You never need to worry about finding a power outlet!

100% DIY

Wire-free, tool-free, worry-free! No complicated power cord wiring to set up, no complicated video post-processing, easy to set-up, easy to use!

Construction Time Lapse Video 1,2,3!

3 steps to create construction time lapse video.

Step.1-Select   Step.2-Shot   Step.3-Done!


Discover the Brinno BCC100
Features

Instant video

BCC100 captures and converts thousands of photos into a Time Lapse video instantly.

LCD Viewfinder

LCD Viewfinder


The 1.44” LCD screen allows you to frame your subject simply.

Instant Video



BCC100 captures and converts thousands of photos into a Time Lapse video instantly.

Long Lasting

Long Lasting


With a set of batteries, 270,000 frames can be captured



F1.2 Aspherical Lens

F1.2 Aspherical Lens


Better low light recording and sharper images.

140° Angle view

140° Angle view


140° field of view. A wider area is captured creating panoramic images of your project.

Weather Resistant

Weather Resistant


IPX4 weather resistant housing, let you records any project, indoors or outdoors.


Worker friendly, Easy to set up!

No Professional photographer is needed to setup and operate or relocate the
construction camera. Any worker will be able to get the job done.


Low Cost Easy to Set Up


Amazing battery life

World record long term, battery operated construction camera, with an outstanding 4 + months of battery life

78 days battery life

140° Super wide angle view

The 140 degree field of view allows you to capture more of the panoramic construction site equally and simply.

140° Super wide angle view

f1.2 Aspherical glass lens

The f1.2 extra low light lens allows you to capture in low light, and see the details often
lost in the dark. You will never miss any on site activities.

Low Cost Easy to Set Up
Dust-proof, weather resistant housing

Yes, we know most construction site are outdoors; and in order to let you capture
your entire construction project in any weather, we provide a weather resistant housing
to prote
c

t your construction camera.

Low Cost Easy to Set Up


Brinno Certified Service Provider
We recognize the value in building successful relationships with an extended network of Time-Lapse Photography/Video technology for utilizing Brinno products; we are continually expanding our partner portfolio. The following companies have taken the next step with Time-Lapse Cameras by completing a Time-Lapse photography/video with additional Brinno Security Products training and certification course. These companies are Brinno authorized service providers and sharing our commitment to best in class customer service and support.

SPECIFICATIONS


Brinno ships the exact product shown in the picture, however, colors and photos shown may vary from actual product colors due to computer monitor display settings. Therefore the you see here may be different then the actual product shipped.

Camera
Model BCC100
LCD Screen 1.44" TFT LCD
Rotate Lens 120°
Waterproof IP X4 (In use with Weather Resistant Housing (ATH110))
Capture Mode
Time Lapse Various time interval
Stop Motion Optional,(In use with Shutter Line (ATS110))
Optics Lens
Aperture f1.2
Lens type Aspherical Lens (glass lens)
Field of View 140° (480P)
112° (720P)
Focal Length 18 mm (35mm equivalent)
Focus Distance 30 cm (Minimum)
Recording
Time Lapse Video Format: AVI
Resolution: 1280x 720, 640x 480
Still Image Format: JPEG (only for using Shutter Line)
Resolution: 1280x 720, 640x 480
Memory Storage SD Card (Supported up to 32 GB)
Time Interval
ASAP Captures 1~ 4 photos per second
Custom From 1 second to 24 hours
Power
Power source Battery: 4 AA Batteries
DC IN: 5V (Micro USB connector)
Battery Life Captures 270,000 photos at ASAP time interval,
Dimension
Size (DxWxH) 64x 46x 106 mm
Weight 120 g (without batteries)
Color Green/ Black
     BCC100
  Time Lapse camera TLC200f1.2
  Weather Resistant Housing (ATH110)
  Camera Wall Mount (AWM100)
  Rubber Strap


The battery life depends on different scene setting:

Time interval Frames captured Est. Battery Life
ASAP 270,000 2.2 days
1 sec 245,000 2.8 days
5 sec 228,000 13 days
10 sec 197,800 23 days
20 sec 137,400 32 days
30 sec 105,200 36 days
1 min 61,800 43 days
5 min 14,300 50 days
10 min 9,180 64 days
30 min 3,700 78 days
1 Hr 1,800
4 Hr 460
24 Hr 78








BCC100 BCC200

Model BCC100 BCC200
Viewfinder 1.44" LCD 1.44" LCD
Image sensor 1.3 MP 1.3 MP HDR
Resolution 1280 x 720 (16:9) 1280 x 720 (16:9)
Aperture f/1.2 f/2.0
Focal length (mm) 18 (35mm equivalent) 19 (35mm equivalent)
Field of view 140° (480P) 112° (720P)
112° (720P)
Aspherical lens
Interchangeable CS mount lens
HDR video
Scene setting
White balance setting
Micro USB output
Webcam function
Extension port
Time interval 0.5 sec, 1 sec-24 hrs 0.3 sec, 1 sec-24 hrs
Battery life 270,000 photos 240,000 photos
Storage media SD/SDHC card SD/SDHC card
Media included 4GB 4GB
Maximum storage capacity 32GB 32GB
Video format AVI AVI
Weather resistant IPX4 (With housing ATH110) IPX4 (With housing ATH120)
Stop Motion video
Still images (JPEG, 1280 x 720)
Batteries required
External power
Holder Camera Wall Mount (AWM100) Industrial-grade aeronautical aluminum alloy clamp
